Tight tolerance and superior finish for absolute compliance and performance
Vimax Technocast is an aerospace parts casting manufacturer in India, supplying precision aerospace castings to aerospace OEMs and tier-1 suppliers across 12-plus countries. We have completed more than 10,000 successful shipments. At our ISO 9001-certified foundry, we cast multiple aerospace components using a wide range of materials, with processes aligned with AS9100D requirements. Our manufacturing approach emphasizes robust testing, efficient traceability, and compliance awareness for multiple export destinations.
Our Portfolio of Aerospace Parts
As an aerospace casting company in India, we manufacture precision casting components for engines, landing gear, structural systems, and other aircraft components.
| Component | Aerospace parts castings |
|---|---|
| Engine components | Turbine blades and vanes, nozzle guide vanes, combustor components, fuel-nozzle bodies, injector housings, selected hot section parts |
| Engine structural components | Engine mounts, bearing support housings, structural frames, struts, linkage components, support rings, selected gearbox housings |
| Structural parts | Wing and fuselage brackets, control-surface fittings and hinges, mounting brackets, latch fittings, bulkhead fittings |
| Landing gear parts | Torque links, axle sleeves, pivot fittings, structural brackets, selected brake housings, actuator components |
| Hydraulic system parts | Valve bodies, manifolds, pump housings, actuator housings, servo-valve bodies, hydraulic fittings |
| Fuel system components | Fuel-manifold bodies, fuel-pump housings, fuel-control housings, filter housings, and other fuel-system components |
| Flight control components | Bellcranks, control levers, actuator clevises, linkage arms, fittings, and certain servo-control housings |
| Environmental control system parts | Bleed-air valve bodies, duct-transition fittings, air-management housings, sensor housings, and heat-exchanger manifolds |
| Power transmission & APU parts | Accessory gearbox housings, bearing housings, gear-case covers, APU structural components, actuator bodies, support brackets |
| Exhaust system components | Exhaust-nozzle segments, exhaust cones, transition ducts, and selected hot-gas-path components |
| Avionics & Instrument housings | Sensor mounts, instrument housings, connector shells, generator and motor housings, and other small electronic enclosures |
| Cabin & Interior hardware | Seat fittings, door-latch bodies, lock components, handle bodies, and specific galley hardware |
Technical Details
The following technical details apply broadly to our range of aerospace castings, from thickness to surface roughness. Technical details for each component can be found on their respective product pages.
| Particulars | Details |
|---|---|
| Process | Investment casting, Lost-wax casting |
| Shell building media | Ceramic, Stucco |
| Materials | Aerospace-grade alloys, including titanium alloys, nickel-based superalloys, cobalt-based alloys, heat-resistant steel, martensitic steel, austenitic steel, and low alloy steel |
| Casting weight range | 40 grams to 150 kg |
| Wall thickness | 1 - 5 mm |
| Tolerance | DCTG 4 - 7, GCTG 3 - 6 |
| Surface roughness | N9-N7 (Ra 6.3-1.6 μm) |
| Machining allowance | 0.25 - 1 mm |
| Surface treatment | Sandblasting, shotblasting, electroplating, deburring, painting |
| Heat treatment | Solution annealing, Tempering, Normalizing, Quenching |
| Compliance | AS9100D, ASME, EN, ISO, DIN, JIS, BIS, GOST |
Our Aerospace Parts Casting Manufacturing Process
Our aerospace investment casting process follows controlled quality procedures aligned with AS9100D requirements. The following breakdown provides additional information.
- Wax moulds: Injecting wax into engineered dies to create wax pattern moulds of the components. Moulds are individually aligned and grouped into a cluster on the sprue.
- Shell building: Investing the sprue into ceramic slurry, followed by stucco coating. We repeat the process up to 10 times to ensure an even thickness and optimal coating.
- Dewaxing: Introducing the wax pattern tree (the sprue) or individual casts into an autoclave for residual moisture and wax removal. This leaves behind a hollow cavity, which is a near-perfect imprint of the product.
- Pouring: The pre-tested molten alloy is gradually poured into the cast via a gate. Vacuum-assisted pouring ensures an even spread, optimal cooling times, and lower risk of hot-corners.
- Knocking: Extracting the cooled castings from the shell using high-pressure water jets. Components are sawed off and the gates ground into stubs.
- Finishing: Removing residual ceramic using shot blasting and chemical baths, and deburring sharp edges.
- Heat treatment: Solution annealing, aging, quenching, tempering, and other processes as required to improve surface strength and hardness.
- Machining: Milling, reaming, and drilling critical contact surfaces, edges, and mating surfaces for excellent tolerances and finish.
- Surface treatment: Electroplating, electropolishing, deburring, sandblasting, or painting to improve corrosion resistance and aesthetics.
- Inspection: Final inspection in line with QMS to check for warp, dents, micro-porosity, and hairline cracks via NDT and spectrometric analysis.
Why Choose Vimax as Your Aerospace Parts Casting Manufacturer
Vimax has supported aerospace OEMs and tier-1 suppliers for more than a decade. Here are the quality and manufacturing practices we use to meet their requirements.
- Ops planning & Risk management: Thorough analysis of the manufacturing procedures to identify critical failure points using FMEA and determine solutions.
- QMS implementation: Quality management system aligned with AS9100D requirements, supported by plant head oversight.
- Competence and training records: Personnel training and competency reports maintained and audited in line with AS9100D requirements for quality assurance.
- Supplier checks: Sourcing from a list of pre-approved suppliers, with a strict requirement of mill certificates for quality control
- Traceability: End-to-end tracking via part number, heat number, chemical analysis, batch number, heat-treatment cycle, inspection records, and NDT testing.
- Component calibration: Regular calibration with documentation to ensure product accuracy to the last millimetre.
- Thorough inspection: NADCAP-aligned NDT lab that checks for microscopic inconsistencies to ensure product integrity.
- Transparency: Details about First Article Inspection pass rate, rejection rate, scrap, wastage, rework, and repair—presented in the non-conformance report.
- Compliance awareness: Conformity with multiple product, process, and material standards along with export and customer special requirements.
“We have our own set of requirements over and above the industry standard, and we were finding it difficult to narrow down a tier-2 supplier who’d adhere to it while meeting the usual requirements. Thankfully, we found Vimax, and they have come through for us every time, even at short notice.”
Procurement Manager
Aerospace OEM, U.S.A.
Ready to Discuss Your Casting Requirements with an Aerospace Casting Company in India?
Whether you are sourcing a new component or evaluating an existing design, our aerospace casting services provide a practical starting point for technical consultation.
FAQs
What destinations do you export to as an aerospace casting company in India?
We export to multiple destinations around the globe, including the U.S.A., Canada, the U.K., France, Italy, Spain, Germany, Poland, the Netherlands, Saudi Arabia, the U.A.E., Japan, Australia, and New Zealand.
What is the MOQ for aerospace castings?
Aerospace castings, because of their material and regulatory requirements, may require higher MOQs than standard industrial castings.
Do you cast aerospace parts with superalloys?
Yes, we cast aerospace parts using superalloys such as Inconel, Hastelloy, and Rene. We also cast with custom and exotic alloys, in line with customer requirements.
What lead times do you offer?
Lead time for the first batch is usually 30–40 days, subject to project requirements. Subsequent batches may require less time.
Do you manufacture castings for industries beyond aerospace?
Yes. In addition to manufacturing aerospace castings, we also produce fire safety equipment parts, defence components, valves, pumps, and more. Please check our digital catalog for additional details or get in touch.
